Description
Built Slash Tough
Traxxas Slash set the standard for durability, performance, and fun by which all other short course trucks are measured. Now Slash 4X4 comes outfitted with the BL-2s brushless power system for even more high-flying, fender-banging, action. The efficient BL-2s delivers all-day fun and endless torque for 4-wheel burnouts and ultra-responsive acceleration. Additionally, Slash 4X4 now comes standard with Traxxas’ Extreme Heavy Duty Upgrade Kit to take the most brutal punishment in stride.
See exploded parts view for this vehicle:
Features
-
Clipless Short Course Body
-
Tough front and rear tube-style bumpers
-
Body reinforcements to prevent pull-through damage
-
Holds tight for intense action
-
Quick and easy removal
-
Smooth appearance with no body posts or clips
-
Extreme Heavy Duty Upgrade Kit Installed
-
Strengthened C-hubs, axle carriers, and steering blocks
-
Extreme heavy duty driveshafts
-
Oversize diameter
-
6mm axles
-
Steel wheel hexes
-
TQ 2.4GHz Transmitter
-
Full-size 2-channel transmitter
-
All-day comfort with precise long-range control
-
BL-2s Waterproof Electronic Speed Control
-
Heat sink accepts accessory cooling fan (TRA3340)
-
Three Programmable Drive Profiles
-
Sport Mode - Forward / Brake / Reverse
-
Race Mode - Forward / Brake
-
Training Mode - 50% Forward / Brake / 50% Reverse (patented)
-
Traxxas EZ-Set one-button setup
-
Built-in two-stage low-voltage detection for LiPo batteries
-
NiMH battery packs: 6-7 cells (7.2 to 8.4 volts)
-
LiPo battery packs: 2 cells (7.4 volts)
-
3300 kV Brushless Motor
-
Integrated cooling fan
-
Low-maintenance design
-
Efficient ball bearings
-
3300 kV
-
Steering
-
Chassis-mounted TRA2056 servo
-
Dual bellcrank design with integrated servo saver
-
Chassis
-
Extended modular composite tub design
-
Secure battery hold-down latch
-
Side nerf bars for impact resistance
-
Suspension
-
Heavy duty suspension arms
-
Oil-filled Ultra Shocks
-
White powder-coated progressive springs
-
Drivetrain
-
Full-time shaft-driven 4-wheel drive
-
Oil-filled steel gear front and rear differentials
-
Large 32-pitch steel spur gear
-
Wheels and Tires
-
Split-Spoke SCT wheels
-
2″ outer diameter, 3″ inner diameter
-
All-terrain SCT tires
-
Sealed Ball Bearings
-
Hex hardware with Rust-Resistant Black Oxide Coating
Specifications
-
Length: 22.4 inches (568mm)
-
Front Track: 11.65 inches (296mm)
-
Rear Track: 11.65 inches (296mm)
-
Center Ground Clearance: 2.83 inches (72mm)
-
Weight (no battery): 5.31 pounds (2.41kg)
-
Height (overall): 7.60 inches (193mm)
-
Wheelbase: 12.75 inches (324mm)
-
Shock Length (front): 3.45 inches (88mm) - Long
-
Shock Length (rear): 3.98 inches (101mm) - XX-Long
-
Tires: Replica short course all-terrain tires
-
Tire Diameter: 4.3 x 1.7 inches (109mm x 43mm)
-
Wheels (front/rear): Gray Split-Spoke SCT wheels
-
Wheel Diameter: 2.2 inches (56mm) (outer)
-
3.0 inches (76mm) (inner)
-
Speed Control: BL-2s electronic speed control
-
Motor (electric): BL-2s 3300 kV sensorless brushless
-
Overall Drive Ratio: 11.82:1
-
Differential Type: Hardened steel bevel, sealed, limited slip
-
Gear Pitch: 32
-
Chassis Structure/Material: Composite tub
-
Drive System: Shaft-driven 4WD
-
Steering: Dual-bellcrank with integrated servo saver
-
Radio System: TQ 2.4GHz (2-channel)
-
Servo: Waterproof digital #2056 servo (80oz-in torque)
-
Skill Level: 1
-
Battery Compartment (L/W/H): 165mm (6.49″) x 50mm (1.95″) x 23/26mm (1.02″/0.90″)
-
Required Batteries: 4 “AA” (transmitter), Vehicle (TRA2960X, TRA2843X or TRA2869X)
What’s In The Box:
-
Slash 4X4 with BL-2s ESC and 3300 kV motor
-
Quick Start Guide
-
TQ 2.4 GHz radio system
-
High quality maintenance tools
What You’ll Need:
-
Charger: Traxxas EZ-Peak Live charger (TRA2971) is recommended for easy and fast charging performance.
-
AA Alkaline Batteries: Four AA alkaline batteries for the transmitter.
