Description
Features:
World's Smallest footprint & Lightweight ESC ever. "28g"
Innovative Double-switch Design: Built-in Electronic Switch, long life, and high reliability saves space on the chassis + Switch w/ extended wire (option)
Programming/Upgrading/Data Reading Wirelessly: Integrated Data logger can record the maximum temperature of ESC and motor as well as the maximum RPM. WiFi Express Module or LCD Programming box can be used to check data easily in the pits. External Programming Port (EPP) is easy to connect and functions as a power port for an additional fan.
Adjustable Throttle and Brake PWM Frequencies: Independent and adjustable throttle & brake PWM frequencies guarantee precise and accurate throttle and brake control for all classes of competitions (esp. the Stock class).
Super Internal BEC: The built-in switch mode BEC with a maximum output of 6A and voltage adjustable between 6V and 7.4V allow the user to use various high voltage servos.
Multi Protection Functions makes running your ESC safe with ESC and Motor overheat protection, low voltage cutoff and throttle signal loss protection.
Easily programmed with the OTA programmer, Multifunction LCD Program Box, and USB Link Software.
ROAR approved for ROAR SPEC racing!
ESC Specifications:
Current Continuous: 80A
Burst: 380A
Battery: 5-7 cells NiMH/NiCd/2S LiPo
Built-in BEC: 6V@3A (switch mode)
Motor Supported: Sensored and sensorless brushless motors
Suitable Motor: 3650 Motors, 1/10 Touring Cars =10.5T, 1/10 Buggy=13.5T
Application: STOCK class of 1/10th Touring Car and Buggy Racing
Cooling Fan: 5V - 7.4V (20x20x8mm)
Wires: 14AWG-200mm
Size: 31.5x25.6x16.1mm
Weight: 28g (Weight is w/o wires, cooling fan)
Motor Specifications:
Turns: 13.5
Kv: 3950
LiPo S: 2-3
Resistance: 0.021O
No-load Current (A): 4.5A
Max. Output Power (W): 322
Current @Max. Output Power (A): 70
Stock Rotor : F7-12.5*25.2-HUS
Weight (g) : 149
